53G / 200L Evacuated Tube Solar Water Heater Solar Place-TSP - ET - 53G - 200L
53G / 200L Evacuated Tube Solar Water Heater Solar Place-TSP - ET - 53G - 200L 53G / 200L Evacuated Tube Solar Water Heater Solar Place-TSP - ET - 53G - 200L

53G / 200L Evacuated Tube Solar Water Heater Solar Place-TSP - ET - 53G - 200L

Brand: Solar Place   Model: Solar Place-ETSWH-TSP - ET - 53G - 200L
0 out of 5
Carisol's Choice
20K+ bought in past month
JMD 170,695.00
No Import Charges & $36.28 Shipping to Jamaica Details
Size72.04 x 85.43 x 62.99 (LxWxH)
Weight275.00 Kg
Made InChina
WarrantyUpto 1yr
Number of Persons8 persons
Heat Retentionupto 72 hrs.
SeriesStandard ( Basic )
Capacity53 Gallon
See More


JMD 170,695.00
Shipping & Import Charges to Jamaica Details Delivery Tuesday, November 11 to Jamaica. Order within 14 hrs 50 mins
Location: Jamaica
In Stock


Ships fromCarisol
Sold byCarisolgroup
Payment3D Secure transation
ReturnsNo refund

Products related to this item

Deals on related products

Product information

Working Pressure0.7 MPa (7 bar)
Country Of OriginChina
Capacity53 Gallons
Number of Persons8 Person
Key FeaturesBasic heating capabilities
Efficiency LevelStandard efficiency
Warranty Period1 year
Collector TypeBasic evacuated tubes
Inner Tank MaterialStainless Steel (Grade 304B Basic)
Outer Tank MaterialStainless Steel (Grade 304B Basic)
Heat Pipe Vacuum Tube Size58mm x 1800mm
Heat Pipe Vacuum Tube Glass MaterialStandard Borosilicate Glass
Heat Pipe MaterialCopper (Grade C11000)
Heat Pipe TypeDry Heat Pipe
Insulation Polyurethane Foam Density40 kg/m³
Heat Retention72 hours
Frame Mounting OptionsDual: Slope / Flat
Frame Tilt Angle30°
Frame MaterialPower Coated Galavanized Steel
Vacuum Degree< 5 x 10^-3 Pa
Absorbing Coating PropertyALN/ALN-SS/CU (Basic)
Emission Ratio≤ 7%
Transition Temperature25°C
Hurricane ResistanceUp to 150 km/h
Impact ResistanceIK06 (Basic)
Star RatingNone
Anti-Lime Scaling Internal ProtectionYes - Innovative anti-scale solution prevents buildup, ensuring easy maintenance.
Anti-Lime Scaling External ProtectionNot included - and can be added on
High Water Pressure ProtectionNot included - and can be added on
CertificationNone
Installation Requirementas a pre-requisite you will be required to have the following in place before the installation team visit you. 1. 1/2 inch Hot and Cold pipe in place on the roof directly in the installation area. 2. 1/2 inch Hot and Cold lock off on the pipes going up to the roof. 3. Standard Water supply from N.W.C, if using a Water Tank the tank must supply water pressure similar to N.W.C. 4. 220V Power Source with long enough cable length to be connected directly to system for back-up 5. Un shaded area for the unit installation
Add On ItemsAdditional items that may or may not be needed depending on your location and if needed will come at an additional cost to you. 1. Hot and Cold Non-Return Valves 2. Pressure Reducing Valves 3. Roof Overlay

Product description

Solar Place TSP - ET - 53G / 200L Evacuated Tube Solar Water Heater Overview

The Solar Place TSP - ET - 53G / 200L is a high-efficiency solar water heater designed with a 200L galvanized steel tank, optimally serving 1 to 5 persons. As part of The Solar Place collection, known for quality and efficiency, this solar water heater is a reliable solution for households with varying hot water needs.

Featuring a high-efficiency galvanized steel solar heater with a flange design, this unit ensures optimal performance and durability. The flange design makes it suitable for households with 1 to 5 persons, meeting diverse hot water requirements.

These Solar Water Heaters are equipped with highly efficient absorbers, boasting a daily average efficiency of over 50%. Heat pipes facilitate the rapid transfer of heat energy into the storage tanks in a single direction. Notably, there is no water in the evacuated tubes, ensuring the solar water heater remains operational even if several tubes are damaged.

Features
  • 200L High-Efficiency Galvanized Steel Tank: Designed for optimal performance and durability.
  • Flange Design: Suitable for households, serving 1 to 5 persons effectively.
  • Highly Efficient Absorbers: Daily average efficiency of over 50%.
  • Heat Pipes: Facilitate rapid transfer of heat energy into storage tanks.
  • Operation Resilience: Continues operation even if several tubes are damaged.
Benefits
  • High Daily Efficiency: Boasts a daily average efficiency of over 50%.
  • Functional Design: Ideal for households with 1 to 5 persons.
  • Rapid Heat Transfer: Heat pipes ensure quick transfer of heat energy.
  • Operational Resilience: Continues functioning despite tube damage.
Conclusion

The Solar Place TSP - ET - 53G / 200L Evacuated Tube Solar Water Heater offers reliable and efficient hot water solutions. With its high daily efficiency and operational resilience, this solar water heater provides consistent performance and durability for your household.
